Helix Engineers manufactures and supplies customized Drum Lifter Cum Tilter machines for chemical, resin, FMCG, pharmaceutical, paint, and other industrial applications across PAN India and for export markets.
Our Model HE-044 Drum Lifter Cum Tilter is designed to lift, clamp, move, and manually tilt MS and HDPE drums for loading, unloading, material shifting, and controlled discharge of liquids or other compatible materials into hoppers, tanks, and processing equipment.
Industries where HE-044 can be used
- Chemical manufacturing
- Resin and adhesive manufacturing
- FMCG and liquid processing
- Paint, ink and coating industries
- Lubricant and oil industries
- Pharmaceutical and specialty chemical production
- Cosmetics and personal care manufacturing
- Industrial cleaning product manufacturing
- Food processing, where suitable hygienic construction is provided
- Warehouses and industrial material-handling facilities
Specification Details
- Model HE-044
- Capacity 350 kg
- Lifting height 5/8/10/12 feet
- Suitable drums MS / HDPE
- Drum clamping Top notch and centre clamping through locking mechanism
- Lifting operation 3-phase electric lever operation
- Tilting operation Manual
- Gearbox Standard make
- Power pack 2 HP with Unicorn make motor
- Wheels 6 × 2 inch, double ball bearings
- Wheel configuration 2 fixed + 2 swivel wheels with 360° rotation
- Wheel material UHMW / Nylon
- Structure Heavy-duty C-channel, box pipe and bent flat bar
- Overall dimensions 1500 × 900 × 2150 mm
Why choose Helix Engineers?
Manufacturer and supplier based in Ahmedabad, Gujarat, India.
PAN India supply and export capabilities.
Customized industrial material-handling solutions.
Model HE-044 designed for 350 kg capacity and 10-foot lifting height.
Suitable for compatible MS and HDPE drum handling.
Electric lifting with manual tilting operation.
Solutions for drum lifting, shifting, loading, unloading, and discharge applications.
Safety note: Before handling hazardous liquids, confirm chemical compatibility, drum integrity, floor conditions, and spill containment. The machine must be rated for the full load at the intended height and reach. For flammable or explosive atmospheres, the electrical equipment and machine must be specifically suitable for that environment.
